CD PLAYER CREEK 50CD

The Evolution 50CD is the next step into a new era of electronics for Creek Audio. Not only does the new Evolution 50CD offer world class CD performance, it also offers the ability to input multiple external digital signals; including (24bit 96KHz) USB. The new Evolution 50CD when paired with the Evolution 50A delivers not only unsurpassable audio performance for its price range but also class leading functionality. This little player is the next big thing.

TECHNICAL SPECIFICATION
DIGITAL INPUTS 2 x SPDIF, 24 Bit 192 kHz, transformer isolated
2 x Toslink, 24 Bit 192 kHz, optically isolated
1 x USB, 24 Bit 96 kHz, galvanically isolated
No additional software drivers are needed.
CD TRANSPORT Custom designed, ICE quality, CD slot-loader, externally clocked for bit perfect performance
SNR > 110dBA unbalanced
DIGITAL OUTPUT 1 x SPDIF and 1 x Toslink optical output, pass-on all input signals
DIGITAL FILTERS Optional digital filters are selectable via the remote
ANALOGUE OUTPUT 2 x RCA un-balanced, 2.0V RMS. 2 x XLR balanced output, 4.0V RMS
AUDIO BUFFERING Op-amp audio buffering and filtering
OUTPUT IMPEDANCE 47 Ohms
POWER SUPPLY 25 Watt toroidal mains transformer with 3 separate secondary voltage windings, with multi-cap power supply decoupling and multiple ultra-low noise discrete power supply voltage regulators.
RC BUS Input/output connection for external IR remote and serial link to Evolution 50A.
DAC TYPE 2 x Wolfson WM8742, 24 Bit 192 kHz, double differential.
INPUT RECEIVER WM8805, multichannel digital input receiver.
OPERATING VOLTAGES 100 – 120V/ 200 – 240V, Switchable
POWER CONSUMPTION 20 Watts (at idle)
WEIGHT 5.5kg
DIMENSIONS W/H/D 430 x 60 x 280mm
FINISHES Silver or black engraved front panels
