CONVERTITORE D/A PRO-JECT DAC BOX E



Convertitore D/A 24bit/192KHz. 2 ingressi, 1 ottico e 1 coassiale. Uscita RCA dorati. Schermatura interna. Componentistica SMD. Consumo in standby meno di 1Watt. Elegante chassis in resina plastica di dimensioni ridotte 120x32x100mm (lxhxp).



Technical specifications

Pro-Ject DAC Box E

Line-level output 1 pair RCA/phono sockets
Output voltage 0,7Vrms
Digital inputs 1x coaxial (S/PDIF), 1x optical (TOSlink®)
D/A converter Texas Instruments TLV320DAC23 Cirrus Logic CS4344. 24Bit/192kHz
Supported audio format PCM (LPCM) (Stereo only, no support for multi-channel formats)
Sampling rates Optical and coaxial input 44,1kHz, 48kHz, 96kHz and 192kHz (coaxial only)
Outboard power supply 18V/500mA DC
Power consumption 200mA DC, <1W in standby
Dimensions W x H x D (D with sockets) 120 x 32 x 100 (106)mm
Weight 250g without power supply
Peso 5,0000 kg
