DENON DJ PRIME GO | CONSOLE A BATTERIA – 2 DESK TOUCHSCREEN 7″

SCHEDA TECNICA

• Audio
  • • Frequency Response: 20 Hz – 20 kHz (+/- 1 dB)
    • Dynamic Range: > 109 dB (A-weighted)
    • Signal-to-Noise Ratio: > 92 dB (A-weighted)
    • Channel Separation: < -88 dB (1 kHz, unity)
    • Headroom:
      • Aux: > 15 dB
      • Mic Input: > 20 dB
      • Outputs: > 15 dB
    • T.H.D.
      • Aux: < 0.01% (1 kHz, unity)
      • Microphone: < 0.02% (1 kHz, unity)

  ---

  • • Analog Input
      • Aux:
        • +15 dBV (maximum)
        • 0 dBV (unity)
      • Microphone:
        • -40 dBV (unity)
        • -54 dBV (minimum)

  ---

  • • Analog Output
      • Master, Balanced:
        • +18 dBu (maximum)
        • +4 dBu (unity)
      • Master, Unbalanced:
        • +15 dBu (maximum)
        • 0 dBu (unity)
      • Booth:
        • +18 dBu (maximum)
        • +4 dBu (unity)
      • Headphone Output: < 40 mW

  ---

  • • Connections
      • (2) XLR outputs (master left/right, balanced)
      • (1) RCA output pair (master left/right, unbalanced)
      • (2) 1/4″ (6.35mm) outputs (booth left/right, balanced)
      • (1) 1/4″ (6.35mm) stereo output (headphones)
      • (1) 1/8″ (3.5mm) stereo output (headphones)
      • (1) RCA input pair (line-level, unbalanced)
      • (2) XLR + 1/4″ (6.35mm) inputs
      • (1) USB ports (for USB drives)
      • (1) USB port (to computer)
      • (1) SD card slot
      • (1) Ethernet port
      • (1) Power adapter input

  ---

  • • Power
      • Connection: DC, Center Positive
      • Voltage: 19V 3.42A
      • Consumption: 30W maximum

  ---

  • • Dimensions (Width x Depth x Height)
      • 411mm x 274mm x 53mm
      • 16.2” x 10.8” x 2.1”

  ---

  • Weight (Without USB and Power Cable)
    • 8.11 lbs.
    • 3.68 kg
